• Supply voltage：DC3.3V-24V

• Optional aperture：1.0/1.2/1.5/1.8


• Output signal: Pulse NPN or PNP


• Maximum detection flow: 1500ml/min


• Detection accuracy: 2%/ 3%/ 5%

• Operating temperature：5~+65℃

• Working lifetime : 50,000Hrs< (≈5.7 years)

◆This product is light and flexible appearance, small size, easy to install.

◆The impeller is always wear-resistant

◆The upper and lower force structures of the seal ring will never leak.

◆Hall elements are imported from Germany and encapsulated with potting compound to prevent water.

◆All raw materials meet ROHS testing standards.
